BEIBEN 6x4 TRACTOR HEADS TOW TRUCK

Product Details

BEIBEN 6x4 TRACTOR HEADS TOW TRUCK



BEIBEN

TRACTOR   TRUCK

ND4254B34J



Traction type

LHD

Drive System

6×4

Cabin

NG80 flat   cabin, air conditioner ,one sleeper

Engine

Brand

WEICHAI

Model

WP10.336 (EuroIII Common   Rail)

Rated power

336hp

Engine displacement

9.726   liters

Gearbox

12JS160T

Clutch

430   Diaphragm type

Steering

TAS85/ZF8098

Axle

Front

BEIBEN   7.5T

Rear

BEIBEN   13T, double reduction axle, ratio:5.921

Max. running speed (km/h)

85

Tire

12.00R20

Spring

13/13

Fuel tank

400L

Kerb weight (kg)

9200

Total mass (kg)

25000

Wheel base (mm)

3450+1450

Overhang (mm) (front/rear)

1410/625

Track (mm) (front/rear)

1995/1800

Approach / departure angle(°)

26/64

Overall Dimensions(L*W*H)(mm)

7135×2495×3340

5th wheel

90#
