Beiben 6x4 prime mover trailer tractor truck best price

Product Details

North Benz tractor truck/beiben tractor heads/ truck for sale





STEYER, MAN, BENZ design platform.   INTERNATIONAL QUALITY STANDARD
Cabin air deflector,air-condition ,single or double  sleeper, USB application, electric window lifter,GPRS management system.   MAN/STEYER cabin
Drive  type Left hand / right hand,   4x2,6x2,6x4,8x4,6x6.
Engine : WEICHA I(WP series ,WD series)  CUMMINS series:
Type Diesel 4-stroke direct injection engine,  6-cylinder in line with water cooling, turbo-charging& inter cooling.
Number of cylinder Inline six-cylinder BOSCH oil pump
Displacement 5.762L, 11.596L
Emission Euro  2,3,4
Max torque (kg.m/rpm) 1 070NM-2000NM@1400-1600rpm
Cl u tch
Type 430 diaphragm construction
Single-plate dry cluth,mechanically operating with air assisted
Gear box ,Transmission
Model FAST FULLER(recommendation), ZF 8098,
Type 9,10,12,16 speeds      AS (  Automatic Synchronizer )
Gear box Mechanical form , Remote control device
Front  axle
Type STYER / HANDE,
Permissble load Kg /axle 65 00 kg,7500kg
Rear  driving axle
Model STYER / HANDE driving axle
Type Pressed axle housing,single/double reduction with planetary wheel reduction.
Permissble load Kg /axle 1 3000kg,16 000 kg
Track 1800/1860
Transmission  ratio 4.42  4.80  5.73  6.72  7.49  8.40  9.94
Tyre  :
    Bias/Radial TYRE  315/80R22.5 / 12.00R20
Braking sytstem
Brake   ABS,ASR
Service brake Dual circuit pneumatic brake
Parking brake Spring energy,compressed air operating on rear wheels
Hanging
Type FR/RR Spring plate,Lug/Multi-leaf spring
Electric equipment
Operating voltage 24v,negative grounded
Battery voltage/capacity 12v/135A,165A
Turning technology ZF8098  hydraulic pressure steering system
Oil Tank :                       38 0L -1000L
Dimension of King pin(5th wheel):  50(2’’),90(3.5’’).
Other option:  PTO, more than 20 colors’ surface, strengthen leaf spring.mainly as your requests.
