Beiben V3 6x4 tractor truck head With WEICHAI Engine
Product Details
Beiben V3 6x4 tractor truck head With WEICHAI Engine
Product Description
| Cab | middle length cab, made by full steel material, anti-crash performance can be ensured by double hollow chamber structure. Inner A/C | ||||
| Kerb weight | 8800kg | ||||
| Gross Vehicle Weight | 25000kg | ||||
| Wheelbase(mm) | 3300+1350 | ||||
| Engine | Brand: | WEICHAI | |||
| Model: | WP10.336 | WP10.375 | WP12.375 | WP10.380E32 | |
| Power (kw/hp): | 247/336 | 276/375 | 276/375 | 280/380 | |
| Max torque(N.m/rpm): | 1250/1200-1600 | 1460/1200-1600 | 1630/1200-1200-1500 | 1600/1800 | |
| Displacement (L): | 9.726 | 9.726 | 11.596 | 9.726 | |
| Transmission | Brand:FAST GEAR Model:9JS150A 9-forward &1-reverse gears | ||||
| Clutch | Single dry frictional disc,Hydraulic boosting | ||||
| Steering | Model:ZJ120D | ||||
| Brake | Service brake:Brake gap can be adjusted automatically, double circulation air brake system Assistant brake:Engine exhaust brake Park brake:Potential springs pressing on middle and rear wheels | ||||
| Frame | Fish belly shape,variable width, variable section side beam structure | ||||
| Front axle (Mercedes Benz Technology) | 7.5 ton non-driving steering axle | ||||
| Middle and Rear axle (Mercedes Benz Technology) | 485Single reduction driving axle | ||||
| Tyre | 12.00R20 | ||||
| Fuel tanker capacity L | 400 | ||||
| Speed Ratio | 4.625 | ||||
| Leaf spring quantity | 3/4 | ||||
