Model

ND42500B34J7

Traction type

6X4

Driving type

LHD

Driver's cab

Long high cabin, double sleeper bunk, A/C

Dimensions in (mm)

Wheel base(mm): 3450+1450

Overall size(mm): 7240x2500x3600

Engine

Maker: Weichai

Diesel 4 stroke direct injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & intercooling

Engine model: WP12.440(440hp)

Emission Standard: EURO3

Maximum output: 1920NM /1200-1500 rpm

Number of cylinder:6

Displacement: 9.726L

Clutch

430mm, hydraulically operating with air assistance

Transmission

Brand: FAST

Model: 12JS200T(12 speeds)

Steering

TAS85

Front Axle

Benz technology 7.5ton

Rear Axle

Benz 13ton double reduction driving axle,Ratio:4.2

Types

12.00R20 Radial tyre

No. of tyre

10+1(spare)

Fifth wheel

3.5’(90#)

Fuel tank(L)

400 Aluminium

Electrics

Operating voltage: 24V, negative grounded

Weight in kg

Kerb weight  8800kg

Total mass   25000kg

Performance

Maximum driving speed(km/h) 110
