10 roues Beiben 2638 camion tracteur for Congo
Product Details
10 roues camion tracteur Beiben 2638
| 2538S /6×4/3450+1450/Long Cab/LHD | ||||||
| Dimension | 6935*2495*3340mm | |||||
| Approaching angle/Departure angle | 20/64° | |||||
| Overhang(front/rear) | 1410/625mm | |||||
| Wheel base | 3450+1450mm | |||||
| Max speed | 100km/h | |||||
| Curb weight | 9200kg | |||||
| Max towing weight | 39670kg | |||||
Max loading on fifth wheel, Permitted(kg) |
15670kg |
|||||
| Slope climbing capability | Max.40% | |||||
| Engine | Model | WP10.380E32,water-cooled,four strokes,6 cylinders in line,turbocharged, directly injection | ||||
| Displacement | 9.726L/Diesel | |||||
| Stroke | 126/130mm | |||||
| Max. power | 309/2200 (kw/rpm) | |||||
| Max.torque | 1750/1300-1400(Nm/rpm) | |||||
| Emission stantard | EuroⅢ | |||||
| Fuel tanker capacity | 400L | |||||
| Clutch | 430, Single dry frictional disc,Hydraulic boosting | |||||
| Gearbox | 12JS200T, mechanism,12 forward gears,2 reverse gear, manual operated, with synchronizer |
|||||
| Gear ratio of gear box | 15.53/12.08/9.39/7.33/5.73/4.46/3.48/2.71/2.10/1.64/1.28/1.00 R:14.86/3.33 | |||||
| Suspension system | Front | Non-free standing leaf spring,telescopic shock absorber with stablizer bar suspension , 13pcs | ||||
| Rear | Non-free standing stablization spring, balance suspension system, 13pcs | |||||
| Brake system | Service brake | Brake gap can be adjusted automatically, double circulation air brake system | ||||
| Assistant brake | Engine exhaust brake | |||||
| Park brake | Potential springs pressing on middle and rear wheels | |||||
| Steering system | TAS85,whole circulation in ball, hydraulic booster | |||||
| Frame | Fish belly shape, variable width, variable sections | |||||
Model |
JOST 90 single direction |
|||||
Height of fifth wheel(mm) (unload) |
1410 |
|||||
Radius of front gap (mm) |
2300 |
|||||
Radius of rear slew (mm) |
2600 |
|||||
| Front axle (Mercedes Technology) | Double-shoe pneumatic brake, non-driving steering axle | |||||
| Middle and Rear axle (Mercedes Technology) | Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle | |||||
| Tyre | 12.00-R20 | |||||
| Electrical system | Battery | 2X12V/135Ah | ||||
| Generator | 28V-35A | |||||
| Starter | 5.4Kw/24V | |||||
| Cabin | NG80B Long-Flat roof cabin with single sleeper Full steel skeleton structure, covered with double layer steel plate; Can be tipped forwardly; High back seat for driver;Electric lifting window ; With inner A/C |
|||||
