Beiben 4x2 towing truck 290hp truck head benz technology tractor truck
New BEIBEN North Benz NG80 4x2 heavy trailer truck tractor head camion hot sale in Africa low price
1. Best Chinese BEIBEN north benz 6x4 8x4 4x2 NG80/V3 Truck low price
2. Mercedes Benz Technology
3. Left handed drive and right handed drive available
4. High quality parts supply
5. Most professional service
Dimension |
5995*2495*3095mm |
|
Approaching angle/Departure angle |
16/40° |
|
Overhang(front/rear) |
1410/1085mm |
|
Wheel base |
3500mm |
|
Max speed |
110km/h |
|
Curb weight |
5800kg |
|
Max towing weight |
35870kg |
|
Max loading on fifth wheel, Permitted(kg) |
12070kg |
|
Slope climbing capability |
Max.40% |
|
Engine |
Model |
WP10.340E32,water-cooled,4 Strokes 6 cylinders in line,turbocharged, directly injection |
Displacement |
9.726L/Diesel |
|
Stroke |
126/130mm |
|
Max. power |
213/2200 (kw/rpm) |
|
Max.torque |
1160/1200-1600(Nm/rpm) |
|
Emission stantard |
EuroⅢ |
|
Fuel tanker capacity |
400L |
|
Clutch |
#420, Single dry frictional disc,Hydraulic boosting |
|
Gearbox |
9JS119B, mechanism,9 forward gears,1 reverse gear, manual operated |
|
Gear ratio of gear box |
11.02/6.55/4.64/3.36/2.71/1.95/1.38/1.00/0.81 R: 11.52 |
|
Suspension system |
Front |
Non-free standing leaf spring,telescopic shock absorber with stablizer bar suspension , 9pcs |
Rear |
Non-free standing stablization spring, balance suspension system, 9+6pcs |
|
Brake system |
Service brake |
Brake gap can be adjusted automatically, double circulation air brake system |
Assistant brake |
Engine exhaust brake |
|
Park brake |
Potential springs pressing on middle and rear wheels |
|
Steering system |
D50,whole circulation in ball, hydraulic booster |
|
Frame |
Fish belly shape, variable width, variable sections |
|
Front axle (Mercedes Technology) |
Double-shoe pneumatic brake, non-driving steering axle |
|
Middle and Rear axle (Mercedes Technology) |
Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle |
|
Tyre |
315/80R22.5 |
|
Electrical system |
Battery |
2X12V/135Ah |
Generator |
28V-35A |
|
Starter |
5.4Kw/24V |
|
Cabin |
NG80B Long-Flat roof cabin with single sleeper |
