Beiben truck for heavy transport/off road truck
Product Details
BEIBEN OFF ROAD TRUCK FOR SALE WITH BEST PRICE AND PROFESSIONAL SERVICE
| Benz design platform. widely exported to middle east,africa,south America | ||||
| Cabin |
air-condition ,single or double sleeper, USB application, Benz cabin,air suspension seat.adjustable steering wheels. |
|||
| Drive type | Left hand / right hand, 4x2,6x2,6x4,8x4,6x6. | |||
| Engine : WEICHA I(Steyr technology) | ||||
| Type |
Diesel 4-stroke,direct injection,6 cylinder in line engine, water cooling, turbo-charging& inner cooling. |
|||
| Number of cylinder | six | Chinese oil pump, option:BOSCH oil pump | ||
| Displacement | 5.762L, | 11.596L | ||
| Emission | Euro | 2,3,4 | ||
| Max torque (kg.m/rpm) | Max 2000NM@1400-1600rpm | |||
| Clutch | ||||
| Type |
φ 430 diaphragm type | |||
| Single-plate dry cluth,mechanically operating with air assisted | ||||
| Gear box ,Transmission | ||||
| Model | FAST FULLER(recommendation), ZF | |||
| Type | 9,10,12,16 speeds option:( Automatic Synchronizer ) | |||
| Steering | ZF8098 | |||
| Front axle | ||||
| Type | BENZ technology axle | |||
| Permissble load | Kg | 7000kg/ 7500kg | ||
| Rear driving axle | ||||
| Model | Benz technology driving axle, | |||
| Type | Pressed axle housing,single/double reduction . | |||
| Permissble load | Kg | 1 3000kg/16000 kg | ||
| Track (mm) | 1800/1860 | |||
| Tyre : | 8.25R-20,11.00-20,12.00-20,12.00R-20,315/80R-22.5 | |||
| Hydraulic system(lifting system): HYVA | ||||
| Braking sytstem | Double lines penumatic (air ) brake, drum brake,option: disc brake | |||
| Length of dump body(mm): 4.2m-9.0m | ||||
| Engine Brake | EVB | |||
| Parking brake | Spring activated,compressed air operating on rear wheels | |||
| Suspension system | ||||
| Type | FR/RR | Leaf Spring, 10/12 | ||
| Electric equipment | ||||
| Operating voltage | 24v,negative grounded | |||
| Battery voltage/capacity | 2x 12v/135A,165A | |||
| Starter | 5.4KW/24V | |||
| Oil Tank : 380L ,400L | ||||
| Dimension of King pin(5th wheel): 50(2’’),90(3.5’’). | ||||
| PTO: (QH50) | ||||
