SPECIFICATIONS FOR TRACTOR TRUCK

Vehicle Specifications

Model

ND41808A35J7

Traction 4X2,6X4,8X4

4X2

Power

290HP

Weight Parameter

Complete Vehicle Kerb Mass(kg)

7020

Maximum authorized total mass (kg)

34850

Dimension Parameter

External Dimensions(mm)

Length (mm)

5995

Width(mm)

2495

Height(mm)

3340,3790

wheelbase(mm)

3500

Performance Parameter

Maximum Speed(km/h)

90

Maximum Gradeability(%)

35

Turning diameter(m)

16

Recommended Configuration

Engine

Engine Type

WP10.290E32

Rated power(kW)/Rev(r/min)

213/2200

Horse power/(hp)

290

Torque(N*m)/Rev(r/min)

1160/1200-1600

Transmission

9JS119B

gearbox

9forward gears

2backward gears

Clutch(mm)

430

Axle

Front Axle

Benz-7.5t

Rear Axle

Benz-13t

Axle load-bearing

Front axle

7.5t

Front axle

13t

Fuel Tank(L)

400

Track(mm)

2045/1800,1838

Front overhang/rear overhang(mm)

16/40

Type

12.00R20

Cabin

Sleeper

none sleeper

OTHER

ABS

 optional

COLOR

 optional

Horse power

290,310, 340 ,380,

420 is optional)

Type

nylon(radial and

tubeless is optional)
