2014 Brand New 25T 6*6 Beiben Dump Truck

Product Details


Best North benz dump truck manufacturer in china

10 years beiben dump  trucks field experience

Beiben china dump truck manufacturing

Mercedes-Benz Technology

Best beiben dumper

2014 Brand New 25T 6*6 Beiben Dump Truck

Company Information

CEEC TRUCKS plant is a heavy automobile business unit with the approval of State Administration for Industry and Commerce and State Development Planning Commission and is one of rare domestic enterprises with the authority of Ministry of Commerce.

Adopting modern enterprise system, the company is a marketing enterprise of various heavy automobile brands, integrating international and domestic trade.

Our Services

1. BeibenSpare parts available for 10 years

2. Engineer is available to make service overseas
3. 24hours online consultation service

Packaging & Shipping

1. All the beiben trucks will be made antirust before shipment

2. Different shipping method for different port, Ro-Ro Vessel, Bulk Vessel, Flat-Rack, Container, etc
3. Shipment tracking

 Light Weight Dump Truck


Mercedes Benz Technology WEICHAI engine 340hp & 380hp North Benz Dump Truck



North Benz NG80 WEICHAI Engine 290hp EUROIII 6x4 30-40t/ton Truck Beiben Dump Truck Tipper Truck

Cabin:

North Benz short cabin, one sleeper, A/C
Radio player(with USB), Safety belt, Adjustable air type, high back and shock absorption
Driver seat with handle and seatbelts
Dash board with all necessary gauges such as (km meter, rpm, oil pressure, temperature, air pressure,
Fuel level)
Headlight, Sun protection on cabin.



Engine:
Engine brand: Weichai
Engine type: Diesel 4-stroke direct injection engine, 6-cylinder in-line
With water cooling, turbo-charging & inter-cooling with exhaust valve brake.
Displacement: 9.726 liters
Max. Output: 290HP
Max torque: 1970NM@1200-1500rpm
Bore/Stroke(mm): 126/130



Clutch:
Clutch: Φ 430 Diaphragm type
Type: Single dry frictional disc, Hydraulic boosting
Gear box:
Model: Fuller 9 speeds(9JS150A), manual, 9-forward and 1 reverse speeds



Steering: ZJ120D
Brake system:
Double-circulate brake system



Axles:
Front axles: Mercedes Benz Technology 7.5 Tons
Rear axles: Benz double Reduction driving axle, Ratio: 1: 5.921(option5.263, 6.733)
Frame: Strengthened frame 300*90*8+6+8
Tyre: 12.00R20
No tyre: 10+1 spare
Spring: 10/13
Fuel tank capacity (L): 300



Weight:
Kerb. Mass: 9200 kg
Towing mass: 25000kg

 Dimensions:

Wheel base (mm): 3800+1450
Front overhang (mm): 1410
Rear overhang (mm): 1687
Front track (mm): 1995
Rear track (mm): 1808/1808
Max. Length(mm): 8347
Max. Width(mm): 250

Max. Heigh(mm): 3384



 Tipper Body

Dimension 5600*2300*1500

Capacity :19.32CBM

Thickness of body steel(mm): floor 6 front 6 side & back 4

Hydraulic System ---  F type lifting

Cylinder: Φ180x4640




















































Working principle

Light Weight Dump Truck Building new profit concept in the age of “light weight” (This series mainly refers to the light dump truck with internal length above 6.5m, classified into rectangular dump body and U-shaped dump body) Energy-saving, high effic

Light Weight Dump Truck

Beiben dump truck in great order from our plant.

north benz dump truck

north benz dump truck

north benz dump truck

north benz dump truck

The best beiben dump trucks, beiben 6*4 dump truck, beiben 8*4 dump truck manufacturer in china.

Beiben dump truck for africa congo

Beiben dump truck for africa congo

Beiben dump truck for africa congo

north benz dump truck

north benz dump truck

north benz dump truck

north benz dump truck

north benz dump truck

north benz dump truck

Beiben dump truck for africa congo

Beiben dump truck for africa congo

PreviousCONGO 380HP 6*4 Beiben Dump Truck

NextKennya Market 380hp 6*4 Beiben Dump Truck Low Price Sale

Success Cases

Beiben 60 T heavy duty dumper export to Douala, Cameroon

November 20th, 2015. beiben 60 T heavu duty dumpers are sucessfully shipped on board, from shanghai seaport, China to Douala seaport, Cameroon. Up to cameroon customer's requirement, our plant have reinforced all the detail for this beiben 2534 dump truck, with high strength carbon steel, we produce this beiben 60 T u type dump trucks.

Beiben 60 T heavy duty dumper export to Douala, Cameroon

Bureau veritas send people to inspect our beiben 2534 dump truck for congo country

Bureau veritas people take inspection for the north benz dump truck that will be exported to CONGO in this month. We are authorized north benz 2529,2534,2538,2542,2546 tipper trucks manufacturer in china, have been qualified by SGS, BV, CONTECNA, ISO. We are willing to supply the best quality beiben dump trucks and beiben tractor truck for congo cu...

Bureau veritas send people to inspect our beiben 2534 dump truck for congo country

Lebanon customer order beiben V3 tractor trucks and tipper semitrailer

Lebanon customer order beiben V3 tractor trucks and tipper semitrailer. Beiben V3 tractor trucks are fully absorbed from Germany BENZ ACTROS trucks cabin, totally meet the EUROPEAN standard, are the top choice of Lebanon customer. we will supply Lebanon customer with the durable quality beiben tractor trucks and best after sale service.   Beib...

Lebanon customer order beiben V3 tractor trucks and tipper semitrailer

Indonesia customer order 25 unit beiben RHD 2534 concrete mixer truck and dump truck

Indonesia customer order 25 unit beiben RHD 2534 concrete mixer truck and dump trucks.   These beiben 10 CBM mixer truck and dumpers are all in right hand driving system , to be suitbale for indonesia road policy. CEEC TRUCKS plant engineer make new design on these beiben mixer truck chassis and dump truck chassis, to make sure customer use th...

Indonesia customer order 25 unit beiben  RHD 2534 concrete mixer truck and dump truck

Tanzania customer order 10 units beiben 2638 right hand drive tractor trucks

beiben 2638 right hand drive tractor trucks in tanzania country, supply the best quality beiben right hand drive tractor trucks , and dump trucks. We aim at supplying the best quality and best price of beiben trucks in tanzania country.   Beiben 2638 tractor truck for tanzania country shipped on board at shanghai seaport, CHINA     &...

Tanzania customer order 10 units beiben 2638 right hand drive tractor trucks

Beiben 20 CBM water tanker trucks are shipped for mombassa, kenya

Beiben 20 CBM water cart trucks are shipped on board to kenya, mombassa.  These beiben RHD water tanker trucks are all based on beiben 2538 truck chassis, with benz quality 6*8 military all wheel drive system, kenya customer can use these beiben 20 CBM tanker trucks for their mine aera. 20 CBM beiben 2538 water trucks, you can get more informa...

Beiben 20 CBM water tanker trucks are shipped for mombassa, kenya
