Beiben 420hp tractor truck 2642S 10 tires truck head for haulage

Product Details

BEIBEN 420HP HAULAGE PRIME MOVER 10 TIRES



420hp 6x4 Beiben Tractor Truck

Model

ND42509B32J

Driving type

6 x 4

Total mass (kg)

25000

Curb weight (kg)

8800

Rated towing weight (kg)

40000

Wheelbase (mm)

3200+1350

Outline dimensions (L*W*H)(mm)

7060x2500x3700

Max. Speed (km/h)

80

Max. Gradeability (%)

35

Fuel consumption under certain conditions (L/100km)

30

Engine model

WD12.42

Engine make

Weichai power

Engine power (kw)

309kw (420hp)

Clutch

Single plate large diaphragm spring Φ430mm clutch

Transmission

Manual , 12 speed

Number of steel plate spring (front / rear)

Left 3 right 4 / Left 9 right 13

Steering gear

Chinese brand

Tire

12.00R20/31580R22.5

Emission standard

Euro 2
