Beiben 6x4 420hp Mercedes Benz Technology North Benz/Beiben tractor truck

Product Details

1.North Benz BEIBEN tractor truck
2.Mercedez-benz technology
3.480hp WEICHAI engine
4.FAST transmission
5.Military axles



Beiben 6x4 420hp Mercedes Benz Technology North Benz/Beiben tractor truck

beiben V3 tractor trucks manufacturer

beiben V3 tractor trucks manufacturer

beiben V3 tractor trucks manufacturer

beiben V3 tractor trucks manufacturer

beiben V3 tractor trucks manufacturer



beiben 420 Hp tractor truck manufacturer

  We are the most professional supplier on beiben V3 tractor trucks, beiben V3 2534, 2538,2540,2542,2548 tractor trucks. The best full solution for customer logistic solutions on north benz V3 tractor trucks.

  Our beiben V3 tractor trucks are ideal versions instead of imported benz actors. With outstanding performance and high quality, . Now our beiben V3 trucks are sold to the worldwide countries and areas, such as Kenya, Ethiopia, Libya, Turkmenistan, Kazakhstan, South Africa, Syria, and so forth.


Wheel base (mm)

3450+1450

Curb weight kg

9300

Engine

Model

WP12.480(WeiChai Engine Based on Styre technology, made in China),water-cooled,four strokes,6 cylinders straight in line,turbocharged, directly injection

Displacement L

12/Diesel

Power, max kw/rpm

309/2200

Emission

EURO3

Fuel tanker capacity L

300

Clutch

Model

φ430, Single dry frictional disc,Hydraulic boosting

Gearbox

Model

12JS200T

Brake system

Service brake

Brake gap can be adjusted automatically, double circulation air brake system

Assistant brake

Engine exhaust brake

Park brake

Potential springs pressing on middle and rear wheels

Steering system

Model

ZF8098

Frame

Fish belly shape, variable width, variable sections

Front axle (Mercedes Benz Technology)

Double-shoe pneumatic brake, non-driving steering axle

Middle and Rear axle (Mercedes Benz Technology)

Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle

Tyre

12.00R20

Electrical system

Battery

2X12V/135Ah

Generator

28V-35A

Starter

5.4Kw/24V

Cab

Long cab, made by full steel material, anti-crash performance can be ensured by double hollow chamber structure.

The Fifth wheel

90 #single



The most professinal supplier on Beiben V3 tractor trucks, CEEC TRUCKS , For your Success.

beiben tractor truck for congo customer

beiben tractor truck for congo customer

Beiben V3 tractor trucks

Beiben V3 tractor truck

Model Engine Model Rated Power Payload Driving Mode
Beiben 2542 WP10.420 420 Hp 50 Ton 6*4
Beiben 2548 WP12.480 480 Hp 80 Ton 6*4
Beiben 2534 WP10.340E32 340 Hp 40 Ton 6*4
Beiben 2542 WP12.420E32 420 Hp 55 Ton 6*4
Beiben 2538 WP10.380E32 380 Hp 45 Ton 6*4

PreviousNorth Benz Weichai Engine 270-480hp 6x4 Beiben RHD Truck Tractor

NextBeiben 6x4 340hp Mercedes Benz Technology North Benz/Beiben tractor truck

Success Cases

15 units beiben 2534 dump truck chassis export to Tanzania

15 units beiben 2534 dump truck chassis arrive the shanghai seaport, CHINA.   These beiben 340 Hp dump truck chassis are with RIGHT HAND DRIVE system, ZF 9 shift transmission, benz front axle and rear axle. All these beiben 2534 dumpers are with Germany BENZ NG80 technology.

15 units beiben 2534 dump truck chassis export to Tanzania

8 units beiben 2534K dump trucks are sucessfully export to CONGO, MATADI

2nd,August,2015. 8 units north benz 2534K dumpers are sucessfully shipped on board, all these north benz 10 wheeler dumper will be used in MATADI, CONGO.   We endeavour to supply congo customer with the best quality on beiben 6*4 drive dumper trucks, supply the beiben 30 T, 40 T, 50 T, 60 T dump trucks.            ...

8 units beiben 2534K dump trucks are sucessfully export to CONGO, MATADI

10 units beiben 20 CBM water trucks working in angola customer's project

Angola customer use our 10 units beiben 2534 water tanker trucks in their road project .   North benz 2534 water trucks are all based on china famous beiben trucks chassis, fully applied Germany Mercedes benz technology, water tanker with latest technology, can payload drinking water and industry water.      All these beiben 340...

10 units beiben 20 CBM water trucks working in angola customer's project

8 units beiben V3 12 wheeler fuel tanker truck export to middel asia country

8 units beiben 40 CBM fuel tanker trucks are sucessfully exported to Middle east country.   As the authorized beiben fuel tanker truck manufacturer in china, we have lots of loyal customer that place order on beiben 4*2 drive fuel truck, beiben 6*4 drive oil tanker truck and beiben 8*4 drive oil fuel trucks.   Beiben V3 fuel tanker trucks...

8 units beiben V3 12 wheeler fuel tanker truck export to middel asia country

10 units beiben 2534 truck chassis, 6*6 driving truck export to CONGO, Brazavaiile

CONGO customer make beiben trucks business with our company more than 3 years, this time they order 10 units beiben 6 wheel driving trucks .   all these beiben 2534 all wheel drive trucks will be used in the mine area, for payloading timber.    Beiben 2534 trucks chassis under waxing before shippment .   Bureau Veritas inspectio...

10 units beiben 2534 truck chassis, 6*6 driving truck export to CONGO, Brazavaiile

Best supplier for China beiben dump trucks in CONGO, pointe noire

CONGO best supplier for north benz dump truck, provide congo customer with best quality beiben 2534,2538,2542 dump trucks.  We will ensure the best after sale service for beiben dump truck, beiben tractor truck and bogie suspension for CONGO customer. Also we can supply congo customer with bogie suspension container semitrailer. Currently, we ...

Best supplier for China beiben dump trucks in CONGO, pointe noire
