Beiben(North Benz) dump truck/6*4 /right hand drive
Model: ND3251B38J Power STAR
With Benz technology and produced under the liscence of Benz. Can work under varying environmental conditions.
Order(MOQ):
110 years beiben dump trucks field experience
Beiben china dump truck manufacturing
Mercedes-Benz Technology
Best beiben dumper
CEEC TRUCKS plant is a heavy automobile
business unit with the approval of State Administration for Industry and
Commerce and State Development Planning Commission and is one of rare
domestic enterprises with the authority of Ministry of Commerce.
Adopting modern enterprise system, the company is a marketing enterprise of various heavy automobile brands, integrating international and domestic trade.
1. BeibenSpare parts available for 10 years
2. Engineer is available to make service overseas
3. 24hours online consultation service
1. All the beiben trucks will be made antirust before shipment
2. Different shipping method for different port, Ro-Ro Vessel, Bulk Vessel, Flat-Rack, Container, etc
3. Shipment tracking
Mercedes Benz Technology WEICHAI engine 340hp & 380hp North Benz Dump Truck
Traction type: 6X4
Driving type: LHD (RHD is optioned)
Wheel base (mm) |
5050+1450 |
|||
Curb weight kg |
12420 |
|||
Engine
|
Model |
WD615.46(Wei Chai engine.Euro II,Based on Styre technology, made in China) |
||
Displacement L |
9.726/Diesel |
|||
Emission |
EURO III |
|||
Fuel tanker capacity L |
300 |
|||
Clutch |
Model |
GFX420, Single dry frictional disc,Hydraulic boosting |
||
Gearbox |
Model |
RT11509C(Based on Eaton Fuller technology,made in China;transmission ,mechanism,9 gears,1 reverse gear,manual) |
||
Brake system |
Service brake |
Brake gap can be adjusted automatically, double circulation air brake system |
||
Assistant brake |
Engine exhaust brake |
|||
Park brake |
Potential springs pressing on middle and rear wheels |
|||
Steering system |
Model |
ZF8098 |
||
Frame |
Fish belly shape, variable width, variable sections |
|||
Front axle (Mercedes Benz Technology) |
Double-shoe pneumatic brake, non-driving steering axle
|
|||
Middle and Rear axle (Mercedes Benz Technology) |
Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle
|
|||
Tyre |
12.00R20 |
|||
Electrical system |
Battery |
2X12V/135Ah |
||
Generator |
28V-35A |
|||
Starter |
5.4Kw/24V |
|||
Cab |
Short cab, made by full steel material, anti-crash performance can be ensured by double hollow chamber structure. Inner |
|||
■Working principle
Beiben dump truck in great order from our plant.
The best beiben dump trucks, beiben 6*4 dump truck, beiben 8*4 dump truck manufacturer in china.
More than 15 years on Beiben 2529 tippers,Beiben2534dumper, Beiben 2538dump trucks , beiben 6*4 dump truck,beiben 10 wheeler tipper trucks, ,beiben 10 wheeler tipper,dumpers.We are the best beiben 10 wheeler dump trucks manufacturer in china.
China baotou 2529 dump trucks is totally applied benz truck technology, with CEEC TRUCKS latest design on the 2529 heavy duty dump trucks , to ensure the best work situation of beiben 2529 tippers .
Beiben 2530 dump truck 6*4 driving, with latest technology on beiben 2530 dump truck chassis, china weichai diesel engine and fast 9 shift transmission. we can supply both new beiben 6*4 heavy truck and used beiben 6*4 trucks .
Beiben 6*4 420 hp dump trucks, with china famous 420 horse power diesel engine, we aim at supplying the best quality north benz 420 hp dumper and parts .
Beiben 2534 off road dump truck is with beiben advanced 6*6 driving system, can be suitable for different kinds of working situation. China beiben 6*6 dump trucks can payload at least 25 ton material in very tough road of africa .
Beiben NG80 6x4 dump truck for congo country, we are the authorized and best manufacturer of congo beiben dump trucks supplier, have exported more than 300 units beiben dump trucks to Congo , pointe noire seaport.
Power Star Beiben 6x4 tipper truck With Low Price , we produce and supply power star 6*4 dump trucks, power star left hand drive dump truck and power star right hand drive dump truck.
Beiben Best Performance NG80 Euro2 6x4 dumper, this is the classic cabin of beiben NG80 dump trucks, with benz truck reliable technology, our beiben NG80 dump truck get great reputation in congo country.
Powerful Beiben 420HP 6x4 dump 10 wheeler trucks, this kind of beiben dump trucks with the stronger beiben 420 hp diesel engine, germany benz technology axle and germany zf8098 steering stem .
