Order(MOQ):
1
We are the most professional supplier on beiben V3 tractor trucks, beiben V3 2534, 2538,2540,2542,2548 tractor trucks. The best full solution for customer logistic solutions on north benz V3 tractor trucks.
Our beiben V3 tractor trucks are ideal versions instead of imported benz actors. With outstanding performance and high quality, . Now our beiben V3 trucks are sold to the worldwide countries and areas, such as Kenya, Ethiopia, Libya, Turkmenistan, Kazakhstan, South Africa, Syria, and so forth.
|
Dimension |
6100*2500*3600mm |
|
|
Approaching angle/Departure angle |
16/43° |
|
|
Overhang(front/rear) |
1515/1085mm |
|
|
Wheel base |
3500mm |
|
|
Max speed |
110km/h |
|
|
Curb weight |
5800kg |
|
|
Standard towing weight |
34260kg |
|
|
Max loading on fifth wheel, Permitted(kg) |
12070kg |
|
|
Slope climbing capability |
Max.40% |
|
|
Engine |
Model |
WP12.375E50，water-cooled，four strokes，6 cylinders in line，turbocharged, directly injection |
|
Displacement |
11.596L/Diesel |
|
|
Stroke |
126/155mm |
|
|
Max. power |
276/1900 (kw/rpm)(375 HP) |
|
|
Max.torque |
1800/1000-1400（Nm/rpm） |
|
|
Emission stantard |
EuroV with OBD |
|
|
Fuel tanker capacity |
300L |
|
|
Clutch |
∮430, Single dry frictional disc，Hydraulic boosting.WABCO Clutch |
|
|
Gearbox |
12JS200T, mechanism,12forward gears,2 reverse gear, manual operated |
|
|
Gear ratio of gear box |
15.53/12.08/9.39/7.33/5.73/4.46/3.48/2.71/2.1/1.64/1.28/1.00 R: 14.86 3.33 |
|
|
Suspension system |
Front |
Non-free standing leaf spring,telescopic shock absorber with stablizer bar suspension |
|
Rear |
Non-free standing stablization spring, balance suspension system |
|
|
Brake system |
Service brake |
Brake gap can be adjusted automatically, double circulation air brake system |
|
Assistant brake |
Engine exhaust brake |
|
|
Park brake |
Potential springs pressing on middle and rear wheels |
|
|
Steering system |
D50,whole circulation in ball, hydraulic booster |
|
|
Frame |
Fish belly shape, variable width, variable sections |
|
|
The Fifth wheel |
Model |
JOST ∮90 single direction |
|
Height of fifth wheel(mm) (unload) |
1410 |
|
|
Radius of front gap (mm) |
2300 |
|
|
Radius of rear slew (mm) |
2600 |
|
|
Front axle (Mercedes Technology) |
Double-shoe pneumatic brake, non-driving steering axle |
|
|
Middle and Rear axle (Mercedes Technology) |
Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle |
|
|
Tyre |
315/80R22.5 |
|
|
Electrical system |
Battery |
2X12V/135Ah |
|
Generator |
28V-35A |
|
|
Starter |
5.4Kw/24V |
|
|
Cabin |
V3 Long-high roof cabin with double
sleepers |
|
The most professinal supplier on Beiben V3 tractor trucks, CEEC TRUCKS , For your Success.
| Model | Engine Model | Rated Power | Payload | Driving Mode |
| Beiben 2542 | WP10.420 | 420 Hp | 50 Ton | 6*4 |
| Beiben 2548 | WP12.480 | 480 Hp | 80 Ton | 6*4 |
| Beiben 2534 | WP10.340E32 | 340 Hp | 40 Ton | 6*4 |
| Beiben 2542 | WP12.420E32 | 420 Hp | 55 Ton | 6*4 |
| Beiben 2538 | WP10.380E32 | 380 Hp | 45 Ton | 6*4 |
beiben 4*2 tractor head for exporting, we are the best supplier of beiben 4*2 prime mover supplier .
North Benz BEIBEN V3 Tractor Truck with EUROIII WEICHAI Engine Engine: WEICHAI Gear box:Fuller 12 Parts available always North Benz BEIBEN V3 Tractor Truck with EUROIII WEICHAI Engine 375hp/380hp/420hp/480hp Engine Power
Mercedes-Benz Benz V3 Tractor Truck with WEICHAI engine latest luxury cabin North Benz BEIBEN V3 Tractor Truck with EUROIII WEICHAI Engine Engine: WEICHAI Gear box:Fuller 12 Parts available always North Benz BEIBEN V3 Tractor Truck with EUROIII WEICHAI Engine 375hp/380hp/420hp/480hp Engine Power
Ready New North Benz V3 EuroIII Common Rail Tractor Head 375HP, Ready New North Benz EuroIII Common Rail Tractor Head 375hp Right Hand Drive Tractor Truck Traction type: 6x4 Driving type: RHD Cabin: Long cabin, Double sleeper, A/C Engine: Brand WEICHAI Model WP10.375/276 EURIII
North Benz Tractor V3 LHD & RHD Tractor Truck with Mercedes Benz technology , Ready New North Benz EuroIII Common Rail Tractor Head 375hp Right Hand Drive Tractor Truck Traction type: 6x4 Driving type: RHD Cabin: Long cabin, Double sleeper, A/C Engine: Brand WEICHAI Model WP10.375/276 EURIII
North Benz Tractor V3 LHD & RHD Tractor Truck with Mercedes Benz technology,1.North Benz 6x4 tractor truck 2.Mercedez-benz technology 3.FAST gearbox 4.Benz technology axles 5.Military quality , Ready New North Benz EuroIII Common Rail Tractor Head 375hp Right Hand Drive Tractor Truck Traction type: 6x4 Driving type: RHD Cabin: Long cabin, Double sleeper, A/C Engine: Brand WEICHAI Model WP10.375/276 EURIII
North BENZ BEIBEN 375hp 6x4 tractor truck with Euro 3 common rail WEICHAI engine,1.BEIBEN 6x4 tractor truck 2.Mercedez-benz technology 3.375hp WEICHAI common rail engine 4.FAST gear box 5.Good performance
North Benz V3(2011model) 290hp (WEICHAI engine) 6x4 EURO III tractor truck,North Benz V3(2011model) 290hp (WEICHAI engine) 6x4 EURO III tractor truck WEICHAI engine, FAST FULLER gear box, BENZ axle
New model North Benz BEIBEN Tractor Truck LHD/RHD with 336hp, 375hp,More than 10 years on exporting experience and spare parts of beiben tractor trucks center 24 hours support, also with our engineer continual efforts, we will ensure the best quality service for you. Currently, Hundreds of beiben tractor trucks,
