Mercedes Benz Technology 340hp & 380hp Beiben North Benz Dump Truck For Algeria

Product Details


Best North benz dump truck manufacturer in china

10 years beiben dump  trucks field experience

Beiben china dump truck manufacturing

Mercedes-Benz Technology

Best beiben dumper

Mercedes Benz Technology 340hp & 380hp Beiben North Benz Dump Truck For Algeria

Company Information

CEEC TRUCKS plant is a heavy automobile business unit with the approval of State Administration for Industry and Commerce and State Development Planning Commission and is one of rare domestic enterprises with the authority of Ministry of Commerce.

Adopting modern enterprise system, the company is a marketing enterprise of various heavy automobile brands, integrating international and domestic trade.

Our Services

1. BeibenSpare parts available for 10 years

2. Engineer is available to make service overseas
3. 24hours online consultation service

Packaging & Shipping

1. All the beiben trucks will be made antirust before shipment

2. Different shipping method for different port, Ro-Ro Vessel, Bulk Vessel, Flat-Rack, Container, etc
3. Shipment tracking

 beiben tractor truck for congo customer

Beiben dump truck for africa congo

Beiben dump truck for africa congo


Mercedes Benz Technology WEICHAI engine 340hp & 380hp North Benz Dump Truck



North Benz NG80 WEICHAI Engine 290hp EUROIII 6x4 30-40t/ton Truck Beiben Dump Truck Tipper Truck

Cabin:

North Benz short cabin, one sleeper, A/C
Radio player(with USB), Safety belt, Adjustable air type, high back and shock absorption
Driver seat with handle and seatbelts
Dash board with all necessary gauges such as (km meter, rpm, oil pressure, temperature, air pressure,
Fuel level)
Headlight, Sun protection on cabin.



Engine:
Engine brand: Weichai
Engine type: Diesel 4-stroke direct injection engine, 6-cylinder in-line
With water cooling, turbo-charging & inter-cooling with exhaust valve brake.
Displacement: 9.726 liters
Max. Output: 290HP
Max torque: 1970NM@1200-1500rpm
Bore/Stroke(mm): 126/130



Clutch:
Clutch: Φ 430 Diaphragm type
Type: Single dry frictional disc, Hydraulic boosting
Gear box:
Model: Fuller 9 speeds(9JS150A), manual, 9-forward and 1 reverse speeds



Steering: ZJ120D
Brake system:
Double-circulate brake system



Axles:
Front axles: Mercedes Benz Technology 7.5 Tons
Rear axles: Benz double Reduction driving axle, Ratio: 1: 5.921(option5.263, 6.733)
Frame: Strengthened frame 300*90*8+6+8
Tyre: 12.00R20
No tyre: 10+1 spare
Spring: 10/13
Fuel tank capacity (L): 300



Weight:
Kerb. Mass: 9200 kg
Towing mass: 25000kg

 Dimensions:

Wheel base (mm): 3800+1450
Front overhang (mm): 1410
Rear overhang (mm): 1687
Front track (mm): 1995
Rear track (mm): 1808/1808
Max. Length(mm): 8347
Max. Width(mm): 250

Max. Heigh(mm): 3384



 Tipper Body

Dimension 5600*2300*1500

Capacity :19.32CBM

Thickness of body steel(mm): floor 6 front 6 side & back 4

Hydraulic System ---  F type lifting

Cylinder: Φ180x4640



















































Working principle

Light Weight Dump Truck Building new profit concept in the age of “light weight” (This series mainly refers to the light dump truck with internal length above 6.5m, classified into rectangular dump body and U-shaped dump body) Energy-saving, high effic

Light Weight Dump Truck

Beiben dump truck in great order from our plant.

north benz dump truck

north benz dump truck

north benz dump truck

north benz dump truck

The best beiben dump trucks, beiben 6*4 dump truck, beiben 8*4 dump truck manufacturer in china.

Beiben dump truck for africa congo

Beiben dump truck for africa congo

Beiben dump truck for africa congo

north benz dump truck

north benz dump truck

north benz dump truck

north benz dump truck

north benz dump truck

north benz dump truck

Beiben dump truck for africa congo

Beiben dump truck for africa congo

Previous380hp north benz 8x4 Beiben 30t dump truck for sale

NextMercedes Benz Technology 340hp & 380hp Beiben North Benz Dump Truck For Algeria

Success Cases

Beiben 2529 dumper in congo customer working site

Beiben 2529 dumper in congo customer working site, this north benz 290 hp dumper is used for transporting mine sand, and other low density materia. we supply this beiben dumper to customer in 2011 year.   Currently this beiben 25 T dump truck still work very good situation.   Our beiben dump trucks quality is very reliable and well accept...

Beiben 2529 dumper in congo customer working site

Beiben 20 CBM water tanker trucks are shipped for mombassa, kenya

Beiben 20 CBM water cart trucks are shipped on board to kenya, mombassa.  These beiben RHD water tanker trucks are all based on beiben 2538 truck chassis, with benz quality 6*8 military all wheel drive system, kenya customer can use these beiben 20 CBM tanker trucks for their mine aera. 20 CBM beiben 2538 water trucks, you can get more informa...

Beiben 20 CBM water tanker trucks are shipped for mombassa, kenya

Algeria customer place order of 10 units beiben 8*4 concrete mixer trucks

10 units beiben 8*4 concrete mixer trucks are sucessfully produces and on shippment from shanghai, china to algeria country.  All these beiben 3134 transit mixer trucks are based on beiben 12 wheeler mixer truck chassis. with CEEC truck latest mixer truck technology. we have great confidence that algeria customer will be satisfied with the qua...

Algeria customer place order of 10 units beiben 8*4 concrete mixer trucks

Beiben 60 T heavy duty dumper export to Douala, Cameroon

November 20th, 2015. beiben 60 T heavu duty dumpers are sucessfully shipped on board, from shanghai seaport, China to Douala seaport, Cameroon. Up to cameroon customer's requirement, our plant have reinforced all the detail for this beiben 2534 dump truck, with high strength carbon steel, we produce this beiben 60 T u type dump trucks.

Beiben 60 T heavy duty dumper export to Douala, Cameroon

Beiben 2538 tractor trucks for kenya construction company

Kenya construction company place order of 5 units beiben 2638 tractor trucks from us.   These beiben 2538 tractor trucks are all 6*4 driving system, RHD steering system for kenya road situation, weichai 380 hp strong diesel engine, Fuller fast 12 shift transmission. Original germany mercedes benz technology front axle and rear axle.   As ...

Beiben 2538 tractor trucks for kenya construction company

Beiben 2638 crane truck shipped board , for congo customer

Beiben 2638 crane truck ship on board   Congo beiben 2638 crane truck shipped on board, we are the most professional beiben 2638 truck mounted crane supplier.   Congo customer order this beiben 2638 crane truck from us, this kind of beiben 2638 crane truck will used in congo country for wood transportation.   China beiben 2638 cargo ...

Beiben 2638 crane truck shipped board , for congo customer
