Use Mercedes Benz Technology 340hp & 380hp Beiben North Benz Dump Truck For Algeria
Product Details
Use Mercedes Benz Technology WEICHAI engine 340hp & 380hp North Benz Dump Truck
Traction type: 6X4
Driving type: LHD (RHD is optioned)
| Beiben NG80B 2534,2538 type 6x4 dump truck | |
| Cab | middle length cab, made by full steel material, anti-crash performance can be ensured by double hollow chamber structure. Inner A/C |
| Kerb weight | 12280kg |
| Gross Vehicle Weight | 25000kg |
| Wheelbase(mm) | 4750+1450 |
| Engine | Brand:WEICHAI Model:WP10.375 Emission Standard:EUROII |
| Power (kw/hp):276/275 Max torque:1460N·m/1200—1600rpm | |
| Type:Diesel Displacement (L):9.726 | |
| Transmission | Brand:FAST GEAR Model:9JS180 9-forward &1-reverse gears |
| Clutch | Single dry frictional disc,Hydraulic boosting |
| Steering | Model:ZJ120D |
| Brake | Service brake:Brake gap can be adjusted automatically, double circulation air brake system Assistant brake:Engine exhaust brake Park brake:Potential springs pressing on middle and rear wheels |
| Frame | Fish belly shape,variable width, variable section side beam structure |
| Front axle (Use Mercedes Benz Technology) | 7.5 ton non-driving steering axle |
| Middle and Rear axle (use Mercedes Benz Technology) | 13ton strengthened axle, double reduction driving axle with inter-wheel differential and differential lock |
| Tyre | 12.00R20 |
| Fuel tanker capacity (L) | 300 |
