New BEIBEN V3 420hp 6x4 tractor trailer truck for Congo
New BEIBEN V3 420hp 6x4 tractor trailer truck for Congo
For HIGHLAND BEIBEN V3
Weichai 380hp,420hp Big Trailer Truck Head
Engine: WEICHAI Driving
type: 6x4
Traction type |
6×4 |
|
Drive System |
LHD |
|
Cabin |
V3 high cab, air conditioner ,two sleepers |
|
Engine |
Brand |
WEICHAI |
Model |
WD12.420 EuroII |
|
Rated power |
420hp |
|
Engine displacement |
11.596 liters |
|
Gearbox |
12JS200T |
|
Clutch |
430 Diaphragm type |
|
Steering |
TAS85 power steering |
|
Axle |
Front |
BEIBEN 7.5T |
Rear |
BEIBEN 13T, double reduction axle, ratio:5.921 |
|
Max. running speed (km/h) |
85 |
|
Tire |
12.00R20 |
|
Spring |
13/13 |
|
Fuel tank |
400L |
|
Kerb weight (kg) |
8800 |
|
Total mass (kg) |
25000 |
|
Wheel base (mm) |
3450+1450 |
|
Overhang (mm) (front/rear) |
1515/825 |
|
Track (mm) (front/rear) |
1995/1800 |
|
Approach / departure angle(°) |
16/60 |
|
Overall Dimensions(L*W*H)(mm) |
7240×2500×3750 |
|
5th wheel |
90# |
