Beiben 6*4 420HP V3 tractor truck

Product Details

Beiben 6*4 420HP V3  tractor truck


Traction type: 6x4

Driving type: Left hand drive

Cabin: Mercedes Benz (double Sleeper), with A/C, electric window lift.



Engine brand: Weichai   EURO III

Engine model: WP12.420E32

Engine type: Diesel 4-stroke direct injection engine, 6-cylinder in-line with water cooling, turbo-charging & inter-cooling

Displacement: 11.6 liters

Max. Output: 420hp@2200rpm

Max torque: 1750NM@1200-1600rpm

Bore/Stroke (mm):126/155



Gear box:Fuller 12 speeds (12JSD200TA)

Steering: D50

Clutch: Φ430 diaphragm type

Front axles: Benz 6.5T front axle

Rear axles: Benz double reduction drive axle

Ratio: 4.2 (4.769, 5.263 is optional)

Tyre: 315/80R22.5     radial tires  10+1

Spring: 3/4, 9/13

Fuel tank capacity (L): 400

Max. speed (km/h): 110

Kerb. mass: 8800 kg

Total mass: 25000kg

Wheel base (mm): 3200+1350

Front overhang (mm): 1515

Rear overhang (mm): 840

Front track (mm): 2045

Rear track (mm): 1800/1800

Approach angle: 16 degree

Departure angle: 60 degree

Dimension (mm): 6905x2500x3800

5TH wheel: 3.5’’ (JOST is optional)
