Beiben V3 Heavy Duty 6x4 Truck Tractor 10 wheeler trucks
Beiben V3 Heavy Duty 6x4 Truck Tractor 10 wheeler trucks
1.shortest delivery time
2.more competitive price
3.reliable and high efficient performance
4.good after-sales service
Vehicle Specifications |
Model |
ND42502B34J7 2540SZ |
|
Traction 4X2,6X4,8X4 |
6X4 |
||
Power |
480HP |
||
Weight Parameter |
Complete Vehicle Kerb Mass(kg) |
8800 |
|
Maximum authorized total mass (kg) |
25000 |
||
Dimension Parameter |
External Dimensions(mm) |
Length (mm) |
7240 |
Width(mm) |
2500 |
||
Height(mm) |
3600,3940,3880,3540 3500,3200,3440,3140 |
||
wheelbase(mm) |
3450+1450 |
||
Performance Parameter |
Maximum Speed(km/h) |
90 |
|
Maximum Gradeability(%) |
35 |
||
Turning diameter(m) |
16 |
||
Recommended Configuration |
Engine |
Engine Type |
WP12.400E32 |
Rated power(kW)/Rev(r/min) |
294/2200 |
||
Horse power/(hp) |
400HP |
||
Torque(N*m)/Rev(r/min) |
2000/1300-1400 |
||
Transmission |
12JS200T |
||
gearbox |
12forward gears 2backward gears |
||
Clutch(mm) |
430 |
||
Axle |
Front Axle |
Benz-7.5t |
|
Rear Axle |
Benz-13t |
||
Axle load-bearing |
Front axle |
7.5t |
|
Front axle |
13t x2 |
||
Fuel Tank(L) |
400 |
||
Track(mm) |
1995/1800,1800 |
||
Front overhang/rear overhang(mm) |
1515/825 |
||
Type |
12.00R20 |
||
Cabin |
Sleeper |
two sleeper |
|
OTHER |
ABS |
optional |
|
COLOR |
optional |
||
Horse power |
290hp,310hp,340hp,380hp 400hp and 420hp is optional |
||
Type |
Nylon,radial and tubeless is optional |
||
