375HP Beiben V3 6x4 trailer head truck For Hot Sale

Product Details
375HP Beiben V3 6x4 trailer head truck For Hot Sale



     1.shortest delivery time

     2.more competitive price
     3.reliable and high efficient performance

     4.good after-sales service





Product Description

 Model: ND4251B34J7

Traction type: 6x4

Driving type: Left hand drive

Cabin: Mercedes Benz (double Sleeper), with A/C, electric window lift.



Engine brand: Weichai   EURO III

Engine model: WP12.480

Engine type: Diesel 4-stroke direct injection engine, 6-cylinder in-line with water cooling, turbo-charging & inter-cooling

Displacement: 11.6 liters

Max. Output: 480hp@2200rpm

Max torque: 1970NM@1200-1600rpm

Bore/Stroke (mm):126/155



Gear box:Fuller 12 speeds(12JS200T)

Steering: TAS85

Clutch: Φ430 diaphragm type

Front axles: Benz 7.5T front axle

Rear axles: Benz double reduction drive axle

Ratio:1:5.921

Tyre: 12.00R20     radial tires  10+1

Spring: 13/13

Fuel tank capacity (L): 300

Max. speed (km/h): 100

Kerb. mass: 8800 kg

Total mass: 25000kg

Wheel base (mm): 3450+1450

Front overhang (mm): 1515

Rear overhang (mm): 825

Front track (mm): 1995

Rear track (mm): 1800

Approach angle: 16 degree

Departure angle: 60 degree

Dimension (mm): 7240x2500x3940

5TH wheel: 2.0’’ (3.5" is optional)
