Wheel base  (mm)

4450+1450

Curb weight kg

11100

Engine

Model

WP12.480(Based on Styre technology, made in China)

Power, max   kw/rpm

480

Emission

EUROII

Fuel tanker capacity  L

400

Clutch

Model

GFX420, Single dry frictional disc,Hydraulic boosting

Gearbox

Model

12JS200T

Brake system

Service brake

Brake gap can be adjusted automatically, double circulation air brake system

Assistant brake

Engine exhaust brake

Park brake

Potential springs pressing on middle and rear wheels

Steering system

Model

ZF8098

Frame

Fish belly shape, variable width, variable sections

Front axle (Mercedes Benz  Technology)

Double-shoe pneumatic brake, non-driving steering axle

Middle and Rear axle (Mercedes Benz Technology)

Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle

Tyre

12.00R20

Electrical system

Battery

2X12V/135Ah

Generator

28V-35A

Starter

5.4Kw/24V

Cab

Long cabin, made by full steel material, anti-crash performance can be ensured by double hollow chamber structure.
