China Beiben 2632K tipper truck dump truck price
BEBEN 2632K TIPPER TRUCK MILITARY QUALITY
Wheel base (mm) |
3800+1450 |
|||
Curb weight kg |
12220 |
|||
Upper body Dimension(Lx W x H) |
5800×2300×1500 sand body |
|||
Engine
|
Model |
WD615.44,water-cooled,four strokes,6 cylinders straight in line,turbocharged |
||
Power, max kw/rpm |
235/2200 |
|||
Max torque |
1250/1100-1600 |
|||
Emission standard |
EUROII |
|||
Fuel tanker capacity L |
300 |
|||
Clutch |
Model |
GFX420, Single dry frictional disc,Hydraulic boosting |
||
Gearbox |
Model |
BEIBEN 5S-112GP(With 9 forward gears,1 reverse gear; Under the license from ZF Germany) |
||
Brake system |
Service brake |
Brake gap can be adjusted automatically, double circulation air brake system |
||
Assistant brake |
Engine exhaust brake |
|||
Park brake |
Potential springs pressing on middle and rear wheels |
|||
Steering system |
Model |
ZF8098,whole circulation in ball type, hydraulic boosting |
||
Frame |
Fish belly shape, variable width, variable sections |
|||
Front axle (Mercedes Benz Technology) |
Double-shoe pneumatic brake, non-driving steering axle
|
|||
Middle and Rear axle (Mercedes Benz Technology) |
Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle
|
|||
Tyre |
12.00R20 |
|||
Electrical system |
Battery |
2X12V/135Ah |
||
Generator |
28V-35A |
|||
Starter |
5.4Kw/24V |
|||
Cab |
Short cab, made by full steel material, anti-crash performance can be ensured by double hollow chamber structure.Can be tipped forwardly; Inner A/C |
