Beiben 2646 truck chassis with V3 cabin, 460 hp diesel strong engine , Good performance and more convenient, China beiben latest V3 cabin , with double bed inside , easily maintenance and repair, mercedes benz 7.5 T front axle and mercedes benz 13 T double rear axle,3450+1450 mm, 12.00R20 tyre.
Order(MOQ):
1Weight:
12000Working Capcity:
40 tonsCabin Type:
Beiben V3 cabin with sleeperDimension ( mm ) :
7240×2500×3600Drive System:
6×4Wheelbase (mm):
3450+1450Engine Power:
460HP/WP12.460NGear Box:
12JS200TRemark:
6×6, RHD is optional
Applications:
Beiben CNG tractor truck chassis with V3 cabin, also called as beiben V3 prime mover, Beiben V3 towing head, beiben V3 trailer tractor, beiben V3 cabin tractor truck.
This congo beiben truck is equipped with V3 long cabin, with 4450+1450 mm wheelbase , germany benz technology NG80B cabin .
The cargo truck Box material optional: Manganese steel & Carbon steel, which is safe and durable.
Key Features:
---- Germany benz V3 cabin, safety and convenience
---- WEICHAI diesel engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- ZF8098 steering system, RHD for kenya country.
---- extremely heavy duty suspension, maximum payload 80 ton
---- Military Germany mercedes benz technology axle.
Specifications:
|
Dimension |
7240*2500*3880mm |
|
|
Approaching angle/Departure angle |
16/43° |
|
|
Overhang(front/rear) |
1515/1085mm |
|
|
Wheel base |
3450+1450 mm |
|
|
Max speed |
110km/h |
|
|
Curb weight |
5800kg |
|
|
Standard towing weight |
34260kg |
|
|
Max loading on fifth wheel, Permitted(kg) |
12070kg |
|
|
Slope climbing capability |
Max.40% |
|
|
Engine |
Model |
WP12.375E50，water-cooled，four strokes，6 cylinders in line，turbocharged, directly injection |
|
Displacement |
11.596L/Diesel |
|
|
Stroke |
126/155mm |
|
|
Max. power |
276/1900 (kw/rpm)(375 HP) |
|
|
Max.torque |
1800/1000-1400（Nm/rpm） |
|
|
Emission stantard |
EuroV with OBD |
|
|
Fuel tanker capacity |
300L |
|
|
Clutch |
∮430, Single dry frictional disc，Hydraulic boosting.WABCO Clutch |
|
|
Gearbox |
12JS200T, mechanism,12forward gears,2 reverse gear, manual operated |
|
|
Gear ratio of gear box |
15.53/12.08/9.39/7.33/5.73/4.46/3.48/2.71/2.1/1.64/1.28/1.00 R: 14.86 3.33 |
|
|
Suspension system |
Front |
Non-free standing leaf spring,telescopic shock absorber with stablizer bar suspension |
|
Rear |
Non-free standing stablization spring, balance suspension system |
|
|
Brake system |
Service brake |
Brake gap can be adjusted automatically, double circulation air brake system |
|
Assistant brake |
Engine exhaust brake |
|
|
Park brake |
Potential springs pressing on middle and rear wheels |
|
|
Steering system |
D50,whole circulation in ball, hydraulic booster |
|
|
Frame |
Fish belly shape, variable width, variable sections |
|
|
The Fifth wheel |
Model |
JOST ∮90 single direction |
|
Height of fifth wheel(mm) (unload) |
1410 |
|
|
Radius of front gap (mm) |
2300 |
|
|
Radius of rear slew (mm) |
2600 |
|
|
Front axle (Mercedes Technology) |
Double-shoe pneumatic brake, non-driving steering axle |
|
|
Middle and Rear axle (Mercedes Technology) |
Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle |
|
|
Tyre |
315/80R22.5 |
|
|
Electrical system |
Battery |
2X12V/135Ah |
|
Generator |
28V-35A |
|
|
Starter |
5.4Kw/24V |
|
|
Cabin |
V3 Long-high roof cabin with double sleepers |
|
Beiben V3 cabin truck, with sleeper bed .
Beiben 10 wheeler cargo truck chassis
China beiben V3 strongest 460 Hp engine, extremely suitable for heavy duty logistic transportation, project logistic, beiben V3 2546 tractor truck, germany benz technology, we supply best quality price for beiben V3 2546 prime mover.
Beiben 2556 Heavy Duty V3 tractor truck is a high-end heavy-duty truck product based on mercedes benz technology. The new Beiben V3 prime mover based on advanced European design concepts. It has the characteristics of high efficiency, technology, safety, environmental protection and comfort, and is designed to meet the needs of the high-end heavy-duty truck market at home and abroad. New Beiben V3 tractor head equipped with high quality WEICHAI diesel engine 560HP, matched with FAST 12 shift manual gearbox, 12 forward and 2 reverse gear. Standard JOST #90 seat that can towing 40tons semitrailer.
Beiben 2646 prime mover with V3 cabin, 460 hp diesel strong engine , Good performance and more convenient, China beiben latest V3 cabin , with double bed inside , easily maintenance and repair, mercedes benz 7.5 T front axle and mercedes benz 13 T double rear axle,3450+1450 mm, 12.00R20 tyre.
Beiben 2646 trailer tractor truck with V3 cabin, 460 hp diesel strong engine , Good performance and more convenient, China beiben latest V3 cabin , with double bed inside , easily maintenance and repair, mercedes benz 7.5 T front axle and mercedes benz 13 T double rear axle,3450+1450 mm, 12.00R20 tyre.
The Beiben 6×6 off-road chassis is built on the Beiben NG80 platform, inheriting the core technologies of Mercedes-Benz heavy-duty trucks. It is powered by a 420 hp engine paired with a 12-speed manual transmission, providing ample power reserves. The chassis features an all-wheel-drive configuration, equipped with differential locks, a multi-range transfer case, and high-performance suspension axles. The braking system is comprehensively designed, offering strong load-carrying capacity and excellent off-road mobility. With high reliability and wide adaptability, this chassis is commonly used to modify into tankers, construction service vehicles, military special-purpose vehicles, and various other specialized applications.
Beiben 10 wheel dumper truck 340/380hp weichai engine manual transmission radial tires Professional service
The Beiben 20,000L water tanker truck is built on the ND1252 chassis, equipped with a WP12.420E32 engine that boasts a power of 309 kW (420HP) and complies with the Euro 3 emission standard. The water tank has a capacity of 20,000 liters, constructed from carbon steel with an oval design. It is fitted with a WEILONG 80QZF60/90S water pump, capable of delivering a flow rate of 60m3/h and a lift of 90m, supporting multi-functional operations including front flushing, rear sprinkling, side spraying, and high-position spraying. This vehicle is suitable for various applications such as urban cleaning, green space irrigation, dust suppression at construction sites, and emergency fire fighting, offering high efficiency and versatility.
china north benz 2536 dump truck, 30 T payloading capacity, famous carbon steel Q345B material, HYVA 149 lifting system, china famous beiben 2529 dump truck chassis, benz technology axle, fast 9 shift transmission, super quality assurance and genuine beiben dump truck spare parts support
North BENZ Beiben Dump truck with different horse power 290hp 340hp 380hp power wheels dump truckDump Truck Engine:WEICHAI North BENZ Beiben Dump truck with different horse power 290hp 340hp 380hp power wheels dump truck
