High Quality 25T 6*4 16CBM-18CBM 380hp Beiben Dump Truck
Beiben(North Benz) dump truck/6*4 /right hand drive
Model: ND3251B38J Power STAR
With Benz technology and produced under the liscence of Benz. Can work under varying environmental conditions.
Order(MOQ):
110 years beiben dump trucks field experience
Beiben china dump truck manufacturing
Mercedes-Benz Technology
Best beiben dumper
CEEC TRUCKS plant is a heavy automobile
business unit with the approval of State Administration for Industry and
Commerce and State Development Planning Commission and is one of rare
domestic enterprises with the authority of Ministry of Commerce.
Adopting modern enterprise system, the company is a marketing enterprise of various heavy automobile brands, integrating international and domestic trade.
1. BeibenSpare parts available for 10 years
2. Engineer is available to make service overseas
3. 24hours online consultation service
1. All the beiben trucks will be made antirust before shipment
2. Different shipping method for different port, Ro-Ro Vessel, Bulk Vessel, Flat-Rack, Container, etc
3. Shipment tracking
Mercedes Benz Technology WEICHAI engine 340hp & 380hp North Benz Dump Truck
Traction type: 6X4
Driving type: LHD (RHD is optioned)
Wheel base (mm) |
5050+1450 |
|||
Curb weight kg |
12420 |
|||
Engine
|
Model |
WD615.46(Wei Chai engine.Euro II,Based on Styre technology, made in China) |
||
Displacement L |
9.726/Diesel |
|||
Emission |
EURO III |
|||
Fuel tanker capacity L |
300 |
|||
Clutch |
Model |
GFX420, Single dry frictional disc,Hydraulic boosting |
||
Gearbox |
Model |
RT11509C(Based on Eaton Fuller technology,made in China;transmission ,mechanism,9 gears,1 reverse gear,manual) |
||
Brake system |
Service brake |
Brake gap can be adjusted automatically, double circulation air brake system |
||
Assistant brake |
Engine exhaust brake |
|||
Park brake |
Potential springs pressing on middle and rear wheels |
|||
Steering system |
Model |
ZF8098 |
||
Frame |
Fish belly shape, variable width, variable sections |
|||
Front axle (Mercedes Benz Technology) |
Double-shoe pneumatic brake, non-driving steering axle
|
|||
Middle and Rear axle (Mercedes Benz Technology) |
Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle
|
|||
Tyre |
12.00R20 |
|||
Electrical system |
Battery |
2X12V/135Ah |
||
Generator |
28V-35A |
|||
Starter |
5.4Kw/24V |
|||
Cab |
Short cab, made by full steel material, anti-crash performance can be ensured by double hollow chamber structure. Inner |
■Working principle
Beiben dump truck in great order from our plant.
The best beiben dump trucks, beiben 6*4 dump truck, beiben 8*4 dump truck manufacturer in china.
