BEIBEN Truck Tractor With Certicfication ISO,GCC,CCC
BEIBEN Truck Tractor With Certicfication ISO,GCC,CCC
Model |
ND4258B34J |
Driving type |
6x4 |
|||
Cab |
Mercedes Benz cabin with air conditioner and single bed |
Drive type |
RHD |
|||
Wheel base (mm) |
3450+1450 |
Dimension (mm) |
6935x2500x3630 |
|||
Kerb. mass |
9200kg |
Total mass |
40000kg |
|||
Front overhang |
1410mm |
Rear overhang |
6255mm |
|||
Front track (mm) |
2022 |
Rear track (mm) |
1800 |
|||
Approach angle |
26 degree |
Departure angle |
64 degree |
|||
Engine |
||||||
Engine Model |
WP10.340NE32 |
Displacement |
9.726 liters |
|||
Max. output |
340hp@2200rpm |
Max torque |
1350NM@1100-1600rpm |
|||
Engine type |
Diesel 4-stroke direct injection engine, 6-cylinder in-line with water cooling, turbo-charging & inter-cooling |
|||||
chasiss |
||||||
Gear box |
12JS160TA |
Clutch |
GF420 spring type |
|||
Front axle |
Benz 7.5T front axle |
Rear axle |
13T Benz double reduction drive axle, ratio=5.921 |
|||
Tyre |
12.00R20 |
Steering |
TAS85 |
|||
