Traction type

6X4

Driving type

Left hand driving or Right hand driving

Dimension(Lx W xH)(unloaded)

10576x2500x3130

Approaching angle/Departure angle(°)

26/20

Overhang(front/rear)          (mm)

1410/2666

Wheel base                   (mm)

5050+1450

Max speed                 (km/h)

90

Curb weight                 (kg)

12000

Loading Weight          (kg)

25,000

Engine

Steyr technology, made in China

Model:WD615.340

water-cooled,four strokes,6 cylinders in line,turbocharged, directly injection With the exhaust valve brake

Displacement     (L)

9.726/Diesel

Bore X stroke     (mm)

126/130

Max power      (kw/rpm)

247/2200 (340hp)

Max torque   (Nm/rpm)

1350/1300-1600

Emission

EURO II

Fuel tanker(L)

400L steel fuel tanker

Clutch

Model

430 Diaphragm type

Gearbox

Model

9JS150 (Fuller)

mechanism,9gears,1reverse gear, manual,

Brake system

Service brake

Brake gap can be adjusted automatically, double circulation air brake system

Assistant brake

Engine exhaust brake

Park brake

Potential springs pressing on middle and rear wheels

Steering system

Model

ZF8098

Frame

Fish belly, shape, variable width, variable sections, side beam structure

Front axle

7.5T: Double-shoe pneumatic brake, non-driving steering axle

Middle and Rear axle

13T: Double-shoe pneumatic brake, casting, double reduction driving axles with inter-wheel & inter-axles differential locks

Transfer case

VG1400

Tyre

12.00R20 Radial tyre Number of tyre:10+1 spare

Electrical system

Battery

2X12V/135Ah

Generator

28V-35A

Starter

5.4Kw/24V

Cab

Using Mercedes-Benz technology NG80B long Cabin, single sleeper with air-conditioner

Full steel skeleton structure, covered with double layer steel plate;

Can be tipped forwardly;

                       Water tank

Steel quality

Carbon steel

Compartment

Single

Loading valve

1

Discharge valve

1

Tube

10meters

Tank capacity (Liter)

20,000

Thickness of the tanker body

the thickness of the shell is 4mm approx;

Dish ends

the thickness of the shell is 5mm approx;
