Vehicle Specifications

Model

ND33100D46J7

Traction 4X2,6X4,8X4

8X4

Power

340HP

Weight Parameter

Complete Vehicle Kerb Mass(kg)

15080

Maximum authorized total mass (kg)

31000

Dimension Parameter

External Dimensions(mm)

Length (mm)

11680/11780/11980

Width(mm)

2500

Height(mm)

3484

wheelbase(mm)

1950+4600+1450

Internal cargo Sizes

Length (mm)

8900

Width (mm)

2300

Height (mm)

1500

Performance Parameter

Maximum Speed(km/h)

90

Maximum Grade ability(%)

35

Turning diameter(m)

16

Recommended Configuration

Engine

Engine Type

WP10.340E32

Rated power(kW)/Rev(r/min)

250/2200

Horse power

340HP

Torque(N*m)/Rev(r/min)

1600/1200-1600

Transmission

12JS160T

Clutch(mm)

430

Gearbox

12 forward gears

2 reverse gears

Axle

Front Axle

BENZ-7.5X2

Rear Axle

BENZ-13x2

Axle load-bearing

Front axle

7500 X2

Rear axle

13000x2

Fuel Tank(L)

300

Track(mm)

2045/2045,1872/1872

Front overhang/rear overhang(mm)

1515/2215,1515/2315

Type

12.00R20

Cabin

Sleeper

none

OTHER

Engine horse power

290hp,310hp,340hp ,380hp,

400hp and 420hp is optional

Tyre

nylon,radial and

tubeless is optional

ABS

optional

COLOR

optional
