Tanzania Beiben 2638 dump truck equipped with a WP10.380 engine, 6x4 drive system, NG80B full steel cabin, and Benz technology front and rear axles is a powerful and reliable vehicle designed for heavy-duty hauling and transportation purposes.
Tanzania Beiben 2638 dump truck is also commonly used in the mining industry. Its can transport bulk quantities of minerals and ores from mining sites. The powerful Benz 7T front technology axles and 13 T double rear axle ensure reliable performance and longevity.
Goods Stock:
15Working capcity:
20 CBM cargoCabin type:
Beiben NG80 cabin, with sleeper bedDimension ( mm ) :
9880×2500×3630Drive system:
6x4, Right Hand DriveWheelbase (mm):
4450+1450Engine power / Model:
380 Hp, WP10.380Gear Box:
12JS200TARemark:
6×6 drive is optionalTanzania Beiben 2638 dump truck is a heavy-duty commercial vehicle designed for transporting and dumping large quantities of materials such as sand, gravel, dirt, and other construction materials. Equipped with a powerful WP10.380 engine, Tanzania Beiben 2638 dump truckk provides the necessary strength and durability to handle demanding tasks in various construction, mining, and infrastructure development projects. The 6x4 drive system of the Beiben 2638 dump truck ensures optimal traction and stability on various terrains, allowing it to navigate rough and uneven surfaces with ease. This drive system also enhances the truck's payload capacity, making it suitable for transporting heavy loads over long distances
The 6x4 drive system of the Beiben 2638 provides excellent traction and stability, making it suitable for off-road construction sites and rugged environments. This allows the truck to navigate challenging terrain and deliver materials to remote locations.
The NG80B full steel cabin of the dump truck provides a safe and comfortable environment for the driver, ensuring that they can operate the vehicle efficiently and effectively. The cabin is equipped with modern amenities and features to enhance the driver's experience and promote safety.
Product Specifications
|
Drive Type |
6x4 LHD/RHD |
|
Cab Type |
Long Cabin |
|
Equipment |
With Air Condition, with bed |
|
Weight |
|
|
Kerb mass(kg) |
12800 |
|
GVW(kg) |
45000 |
|
Dimensions |
|
|
Max. length(mm) |
9880 |
|
Max. width(mm) |
2500 |
|
Max. height(mm) |
3630 |
|
Front/Rear overhang(chassis) |
1410/1870 |
|
Wheel base(mm) |
4450+1450 |
|
Track width(mm) |
1995/1808 |
|
Box size |
|
|
Length (mm) |
5600 |
|
Width (mm) |
2500 |
|
Height (mm) |
1500 |
|
Thickness of Steel |
Floor 8mm, side 6mm |
|
Tipping type |
Front tipping |
|
Performance |
|
|
Max. speed (km/h) |
75 |
|
Max. gradeability (%) |
30 |
|
Approach/Departure angel (°) |
26/32 |
|
Engine |
|
|
Brand |
WEICHAI BRAND |
|
Model |
WP10.380E32 |
|
Power (kw/hp) |
280kw/380hp |
|
Max torque (N.M)/rpm |
1500--1800 |
|
Displacement (L) |
9.726 |
|
Emission Standards |
Euro III (optional) |
|
Transmission |
|
|
Brand |
FAST |
|
Model |
9JS180 |
|
Control type |
Manual |
|
Gear Shift |
9-forward & 1-reverse speeds |
|
Clutch |
|
|
Type |
Single plate,diaphragm spring |
|
Diameter (mm) |
Φ430 |
|
Action |
hydraulically operating with air assistance |
|
Brakes |
|
|
Type |
Drum |
|
Service Brake |
With dual-circuit compressed air brake |
|
Park Brake |
Power spring brake acting on rear wheel |
|
Auxiliary Brake |
WEVB |
|
Steering |
ZJ120D/D50/TAS85 |
|
Chassis |
Ladder structure with parallel straight |
|
Dimensions (mm) |
300x90x8+6+8 |
|
Suspension |
|
|
Front |
Longitudinal leaf spring |
|
Rear |
Inverted leaf spring stabilizator suspension |
|
Axles |
BENZ TECHNOLOGY |
|
Front |
BENZ TYPE: 7.5 tons |
|
Rear |
BENZ TYPE: 13tons |
|
Ratio |
5.921 |
|
Tyre |
12.00R20 radial tire |
|
Fuel tank |
|
|
Tank capacity(L) |
300 |
|
Material |
Aluminum alloy |
|
Electrics |
|
|
Type |
24V |
|
Starter |
5.58kw (24) |
|
Generator |
2.0kw (28V 70A) |
|
Battery |
2x135Ah |
Congo beiben 6x4 drive rigid truck chassis
North benz 380 hp dump truck is widely for transporting mine stone and construction material, more than 10 years great experience in north benz 10 wheeler dump truck manufacturing, we aim at supplying the best quality and price for beiben 2538 10 wheeler dump truck.
10 wheeler North benz 380 hp dump truck is widely for transporting mine stone and construction material, more than 10 years great experience in north benz 10 wheeler dump truck manufacturing, we aim at supplying the best quality and price for beiben 2538 10 wheeler dump truck.
As the biggest manufacturer of NG80B 380 hp dump trucks ,we continue designing the super quality for beiben NG80B 10 wheeler dump truck. Beiben NG80B 380 hp dump trucks are with china famous weichai diesel engine, 6*4 driving sytem and fast 12 shift transmission.
North Benz 2538 K dump truck for sale , weichai 380 Hp diesel engine fast 9 shift transmission ,12,00R20 radial tires , HYVA 157 lifting system
Congo beiben 2534 camions benne , 6*4 driving system, weichai WP10.340E diesel engine , fast 9 shift transmission, 3800+1450 mm wheelbase, 12.00R20 tyre, beiben dump truck cargo box 20 CBM capacity.
China beiben 380 hp dump truck manufacturer, 6*4 driving system, weichai brand 380 diesel engine, fast 9 shift transmission, 3800+1450 mm wheelbase, 12.00R20 tyre. 20 CBM dump cargo box capacity.
beiben 50 T heavy duty dump truck,The unique structure of the tray is part of the essence of beiben dump truck, the structure to replace the traditional side frame dumper, cancelled the container underframe,U shaped and U shaped container tightly combined tray,enlarge the contact area
Beiben 6*4 drive dump truck chassis, cargo box 19 CBM capacity, payload around 60T rock stone or mine material , With 10 years experience in beiben dump trucks producing experience, Germany benz technology axle, and Q550 steel cargo box.
Beiben 2638 6×4 dump truck, equipped with WEICHAI 280kw/380hp engine, FAST 9JS180 gearbox, 9 forward gears and 1 reverse gear, has strong power and flexible speed selection. The vehicle adopts a short cab design, with a maximum length of 9880mm and a cargo box size of 5600mm×2500mm×1500mm, which can meet various engineering transportation needs. It has excellent safety performance and is equipped with a dual-circuit compressed air brake system, making it a powerful assistant in engineering projects.
