Beiben 2638 off road knuckle crane truck incorporates Mercedes-Benz technology in its NG80B cabin, prioritizing operator comfort and safety with ergonomic design, noise reduction, and enhanced crash resistance. The Benz-derived front and rear axles further reinforce durability and load-bearing capacity, supporting smooth maneuverability in off-road conditions. Its 6x6 drive system ensures exceptional traction, enabling the truck to navigate mud, gravel, or uneven surfaces with ease. The 14.00R20 tires provide robust grip and stability, ideal for heavy lifting and transportation on rugged terrain.
Mounted on the chassis is the XMCG 5-ton knuckle boom crane, offering a maximum lifting capacity of 5 tons and a flexible working radius. The crane’s articulating design allows precise load positioning, making it invaluable for material handling, equipment installation, and logistics in confined spaces.
Working capcity:
5 T craneCabin type:
Beiben NG80 cabin, with sleeper bedDimension ( mm ) :
9830 x 2600 x 3830Drive system:
6×6, LHDWheelbase (mm):
5050+1450Engine power / Model:
380HP, WP10.380E32Gear Box:
12JS200TARemark:
14.00R20 tyres, RHD optionalBeiben 2638 6×6 all-wheel-drive crane truck is engineered for heavy-duty lifting and off-road versatility, integrating advanced components to ensure robust performance. At its core lies the WP10.380E32 engine, a 9.7-liter inline-six-cylinder diesel powerplant delivering 380 horsepower and 1,500 Nm of torque. Beiben 6x6 off road drive crane truck drivetrain further incorporates Mercedes-Benz-inspired 6×6 off-road system, featuring a lockable inter-axle differential and individual axle locks to maximize traction on uneven surfaces.
The beiben 2638 crane truck chassis employs Benz-derived NG80B technology, exemplified by the NG80B cabin. This operator compartment prioritizes ergonomics and safety, offering reinforced structural integrity, vibration damping, and a panoramic windshield for enhanced visibility. The front and rear axles, leveraging Mercedes-Benz engineering, provide a gross axle load capacity of 16 tons (front) and 20 tons (rear), ensuring stability under heavy loads.
Mounted on 14.00R20 radial tires with deep tread patterns,beiben 6x6 knuckle crane truck excels in mud, gravel, and rocky environments. These high-flotation tires minimize ground pressure, reducing slippage during crane operations. The crane itself is a XCMG 5-ton knuckle-boom model, featuring a 4-stage hydraulic telescopic arm with a maximum lifting radius of 18 meters.
Applications of Beiben 2638 6×6 All-Wheel Drive Crane Truck
Heavy-Duty Material Handling in Rugged Terrains
Equipped with a 6×6 off-road drive system, Mercedes-Benz NG80B cabin, and 14.00R20 tires, the Beiben 2638 excels in transporting and lifting heavy loads (up to 5 tons via its XMCG crane) across challenging environments.
Efficient Logistics in Industrial Sectors
Powered by the WP10.380E32 engine (380 hp) and FAST 9JS160T transmission, this truck delivers reliable torque and fuel efficiency for long-haul transportation of machinery, equipment, or bulk materials.
Specialized Infrastructure Maintenance
The truck’s crane, paired with precise hydraulic controls, facilitates maintenance of power lines, telecommunication towers, or urban utilities. The ergonomic NG80B cabin ensures operator comfort during prolonged tasks, while the 6×6 system provides traction for accessing elevated or confined workspaces, reducing reliance on additional equipment in municipal or industrial upkeep projects.
Product Specifications
|
BEIBEN 6x4 truck mounted 5Ton knuckle boom crane |
|
|
Emission Standard |
EURO 3 |
|
Chassis type |
Cargo truck type |
|
Chassis brand |
Beiben |
|
Driving Type |
6×4 |
|
Dimensions |
|
|
Wheelbase(mm) |
4450+1450 |
|
Overall Dimension(mm) |
Approx. 9960×2500×3348 |
|
Cargo box dimension(mm) |
7000x2300x800 |
|
Weight parameters |
|
|
GVW(kg) |
25,000kgs |
|
Curb weight(kg) |
Approx. 13,550kgs |
|
Real load weight(kg) |
More than 20,000kgs |
|
Chassis parameter |
|
|
Front axle |
7 Ton load capacity, drum brake |
|
Rear/middle axle |
18Ton/axle (2 axle combined) |
|
Front/rear overhang(mm) |
1410/2530 |
|
Approach angle (°) |
34 |
|
Departure angle (°) |
24 |
|
Max speed (km/h) |
85 |
|
Suspension |
Leaf spring suspension |
|
Engine performance |
|
|
Engine model |
WP10.380 (WEICHAI brand) |
|
Engine type |
Straight in-line, 6 cylinders, 4 strokes, water-cooling, Turbo charge with inter-cooling, diesel engine |
|
No. of cylinders |
Straight-6 cylinders |
|
Displacement(L) |
9.726L |
|
Max. output (KW) |
279kw (380hp) |
|
Fuel type |
Diesel |
|
Max. output (kw/Ps/rpm) |
279kw(380ps) /2200 rpm |
|
Max torque/Speed (N.m/rpm) |
1460 N.m/1200-1600rpm |
|
Tire specification |
12.00R20, total 10 units tire+1 spare tire |
|
Drive Line |
|
|
Clutch description |
¢430, dry single plate, hydraulic control booster, mechanical operation with hydraulic assistance |
|
Transmission |
12 forwarder, 2 reverse gear, synchronous meshing by manual |
|
Braking system |
Service brake: Brake gap can be adjusted automatically double circulation air brake system |
|
Suspension system |
|
|
Front axle |
Semi-elliptic leaf springs shock absorbers |
|
Rear axle |
Torsion bar semi-elliptic leaf springs |
|
Electrical Equipment |
|
|
Voltage |
24V |
|
Batteries |
2X12V/135Ah |
|
Starter |
6.2Kw/24V |
|
Cab description |
|
|
NG80 long cab, with one sleeper, cool and heating air-conditioner, Hydraulic suspension driver's seat, four point safety belt for driver and co-driver With FM/AM radio player, USB interface |
|
|
Crane |
|
|
Type |
Knuckle boom crane, 4 sections |
|
Max. lifting capacity |
5000 kg |
|
Max. lifting height |
12.8 meters |
|
Max. working range |
10 meters |
|
Hydraulic outriggers |
2 units |
Beiben 2638 6×6 All-Wheel Drive Crane Truck Technical Overview
1. Powertrain System
The Beiben 2638 integrates a WP10.380E32 engine, a high-performance 9.7-liter diesel powerplant from Weichai Power. Delivering 380 horsepower and 1,500 Nm of torque, this Euro III-compliant engine ensures robust power output for heavy-duty operations. Its advanced fuel injection and cooling systems enhance efficiency and durability under extreme loads.
2. Transmission System
Equipped with a FAST 9JS160T manual transmission, this truck offers nine forward gears and one reverse gear. The transmission’s optimized gear ratios and synchronized shifting mechanism enable seamless power delivery across diverse terrains. Designed for reliability, it supports heavy towing and off-road driving conditions.
3. Cabin Design
The Mercedes-Benz NG80B-inspired cabin prioritizes ergonomic comfort and safety. Featuring a reinforced steel structure, adjustable seating, and climate control, it ensures operator comfort during extended missions. The cabin’s panoramic visibility and noise reduction technology enhance operational precision and reduce fatigue.
4. Axle Configuration
The truck utilizes Mercedes-Benz-technology axles for superior load-bearing capacity. The front axle employs a rigid I-beam design, while the rear axle incorporates a hypoid gear system for optimal torque distribution. Both axles are engineered for durability, supporting a GVWR of up to 38 tons.
5. Drivetrain and Off-Road Capability
The 6×6 all-wheel-drive system ensures exceptional off-road traction. A three-differential layout (front, center, and rear) allows independent wheel torque control, enabling navigation through mud, sand, and steep gradients. The system’s lockable differentials further enhance stability on uneven surfaces.
6. Tire Specifications
Mounted with 14.00R20 radial tires, the truck balances load capacity and terrain adaptability. These high-flotation tires provide a large contact area, reducing ground pressure and improving grip on soft or rocky surfaces.
7. Crane Integration
The XCMG 5T knuckle boom crane offers a maximum lifting capacity of 5 tons with a 360-degree rotation. Its hydraulic telescopic arm and precision controls enable flexible cargo handling, suitable for construction, logistics, and emergency rescue scenarios.
The Beiben 2638 6×4 knuckle boom crane truck is a multi-functional engineering vehicle that integrates efficient transportation and lifting operations, widely used in logistics, construction, power, and other fields. It is equipped with an XCMG knuckle boom crane, featuring a maximum lifting capacity of 5 tons, a maximum lifting height of 10.3 meters, and a rotation angle of 420°, demonstrating excellent lifting performance. Additionally, the vehicle adopts a 6×4 drive configuration and is powered by a robust Weichai WP10.380E32 engine, ensuring stable operation under various complex working conditions.
The Beiben 5-ton knuckle boom crane truck is a specialized vehicle that integrates cargo transportation and lifting operations. It adopts a high-quality chassis from the Beiben brand, paired with a 5-ton knuckle boom crane, making it suitable for lifting operations in various complex environments. Whether it's for construction sites or municipal maintenance within cities, or for road repairs and agricultural operations in rural areas, this truck-mounted crane can meet the diverse needs of users with its outstanding performance.
beiben 5 T crane truck supplier, china best beiben crane truck manufacturer, based on beiben 2538 truck chassis, with XCMG 5 T capacity crane, 40 T capacity reinforced cargo box.
congo beiben 2638 trucks, based on china beiben 2638 truck chassis, weichai 380 hp euro 2 engine, fast 9 shift transmission, 5050+1450 mm wheelbase, 12.00R20 tyre, benz 7 ton heavy duty front axle, benz 16 T double rear axle, heavy duty type cargo box with 40 T capacity, suitable for congo country.
The Beiben 2638 crane truck is a heavy-duty commercial vehicle designed for transporting and lifting heavy loads. This truck is built China beiben 2638 heavy duty truck chassis with NG80B full steel cabin, known for famous weichai diesel engine and Fast 9JS160T all terrian transmission. The Beiben 2638 crane truck features a powerful 380 horsepower engine and a maximum loading capacity of 25 tons, making it suitable for handling a wide range of construction and industrial applications. The crane attached to the truck is capable of lifting heavy objects and materials with ease, making it an essential tool for any construction site or industrial project.
Beiben 2638 with XCMG 5-ton folding arm truck crane is a heavy-duty engineering machinery with stable performance, safety and reliability. As the chassis that carries this crane, Beiben 2638 has strong power output and excellent control performance, ensuring the efficient operation of the crane at the construction site. The XCMG 5-ton folding arm truck crane has a stable lifting capacity and flexible folding arm design, which can meet the lifting needs in different construction scenarios.
Beiben 2638 heavy-duty crane truck integrates robust engineering with specialized functionality, designed for demanding industrial and construction tasks. At its core lies the WP10.380E3 engine, a 10.3-liter inline-six-cylinder diesel powerhouse manufactured by Weichai Power. This turbocharged engine delivers 380 hp (280 kW) at 2,100 rpm and a peak torque of 1,500 Nm at 1,200–1,600 rpm, complying with Euro III emission standards.
Beiben 2638 cabin truck-mounted crane combines robust engineering with versatile material-handling capabilities. This integrated vehicle features a 6x4 all-wheel-drive chassis powered by a Weichai WP10.380E32 diesel engine, delivering 380 horsepower and 1,500Nm torque for off-road mobility.Equipped with a high-torque hydraulic system and reinforced outriggers, the 2638 model maintains operational integrity under extreme loads while complying with international safety standards. Its dual-purpose nature as both transport vehicle and mobile crane significantly reduces operational costs and downtime compared to traditional crane-truck combinationsThe crane's articulated boom, with a maximum lifting capacity of 8-12 metric tons and a working radius extending up to 16 meters
The Beiben 6×6 all-wheel drive water truck, with a gross vehicle weight of 25,000kg, is equipped with a Weichai 380HP engine, a 20,000-liter large-capacity water tank, and an efficient water pump. It features front, rear, side spraying capabilities, as well as a high-pressure water gun. Its sturdy design, powerful engine, efficient operational capabilities, and convenient operation make it an ideal choice for urban road cleaning, fire-fighting assistance, and green space irrigation.
