The Beiben 8000L Water Truck is a professional multi-functional sanitation vehicle built on the Beiben 1929 chassis. It is equipped with a 290-horsepower Weichai engine, an 8000L large-capacity carbon steel water tank, and a high-efficiency water pump system with a flow rate of 40 m³/h and a spraying width exceeding 14 meters. The vehicle features front/side/rear multi-directional sprinklers and a high-pressure water cannon with a range of 23 meters, making it suitable for various tasks such as road cleaning, greening irrigation, dust suppression, and more. With a 9-speed transmission and a 13-ton rear axle for load-bearing, it ensures operational stability, making it an ideal choice for urban sanitation and landscaping.
Working capcity:
8000 litersCabin type:
Beiben NG80 cabin, with sleeper bedDimension ( mm ) :
8200×2550×3100Drive system:
4×2, left hand driveWheelbase (mm):
4800 mmEngine power / Model:
290HP/WP10.290E32Gear Box:
9JS150ARemark:
4×4, RHD is optionalThe Beiben 8000L Water Truck is a multi-functional sanitation vehicle with a 4×2 drive configuration. It is powered by a Weichai WP10.290E32 engine, delivering 290 horsepower with a displacement of 9.726L, providing ample power for water-spraying operations. This left-hand-drive specialized water truck has a gross vehicle weight of 19,000 kg, with a 7-ton front axle and a 13-ton rear axle, ensuring stability during full-load operations. As a flagship model in the Beiben water tank truck series, its 8000L large-capacity water tank supports long-duration continuous operations, making it particularly suitable for large-scale tasks such as urban road cleaning and landscaping.
The core of this Beiben water bowser is its high-efficiency water pump system, which achieves a flow rate of 40 m³/h and a vertical suction lift of ≥6 meters, enabling self-priming startup within 5 minutes. The 4mm carbon steel water tank is treated with anti-corrosion coating and features front, side, and rear multi-directional nozzles, providing a spraying width of ≥14 meters and a water cannon range of ≥23 meters for comprehensive coverage. The Beiben water cannon truck utilizes a professional hydraulic control system, allowing operators to adjust water pressure and spray modes via a centralized control panel in the cab. Its specially designed 45-meter head performance enables the vehicle to handle specialized tasks such as high-rise building facade cleaning.
In terms of the powertrain, the Weichai six-cylinder engine delivers a maximum torque of 1,160 Nm at 1,200–1,600 rpm, paired with a 9JS150A nine-speed transmission to achieve an optimal balance between power and fuel efficiency. Test data shows that the Beiben 8000L Water Spray Truck can reach a top speed of 90 km/h. The suspension system, featuring a 10-leaf front and 13-leaf rear spring design, ensures driving stability across various road conditions. A dual-circuit air brake system, combined with an engine exhaust brake, guarantees safety during heavy-load downhill driving. The configuration of 12.00R20 radial tires further enhances off-road capability in complex terrain.
Product Specifications
|
General Specification |
||
|
Chassis Model |
Beiben 1929 |
|
|
Series |
NG80 |
|
|
Wheel Traction / Drive Style |
4×2 |
|
|
Gross Vehicle Weight |
kg |
19000 |
|
Steering Wheel Position |
LHD/RHD |
LHD (Left Hand Drive) |
|
Engine |
||
|
Model |
WP10.290E32 |
|
|
Brand |
WEICHAI |
|
|
Displacement |
9.726L |
|
|
Type |
In-line, Six-cylinder, Four-stroke, Water-cooled, Direct Injection, Intercooled Turbocharged Diesel Engine |
|
|
Engine Classification / Standard |
EURO III EGR |
|
|
Bore/Stroke |
mm |
126/130 |
|
Rated Horse Power |
hp |
290 |
|
Net Power |
KW/rpm |
213KW/2200rpm |
|
Torque (Nm/rpm): |
Nm/rpm |
1160Nm @ 1200-1600rpm |
|
Clutch & Gear Box Systems |
||
|
Clutch |
BEIBEN's 430 diaphragm spring clutch |
|
|
Gear Box |
9JS150A |
|
|
Gear Speed/Lever |
9 forward/ 1 reverse |
|
|
Gear Ratio |
12.57,8.39,6.15,4.59,3.4,2.47,1.81,1.35 |
|
|
Axle & Steering |
||
|
Steering Model |
8098 |
|
|
Front Axle |
7T |
|
|
Rear Axle |
13T, Drum Brake |
|
|
Ratio of Rear Axle |
5.263 |
|
|
Loading Capacity per Axle |
front |
7000kg |
|
rear |
13000kg |
|
|
Brake System & Suspension |
||
|
Service Brake |
dual circuit compressed air brake |
|
|
Auxiliary Brake |
engine exhaust valve brake |
|
|
Parking Brake |
front |
spring energy |
|
rear |
compressed air |
|
|
Suspension Type |
front |
10pcs leaf spring |
|
rear |
13pcs leaf spring |
|
|
Wheels & Tires |
||
|
Wheel Type |
Radial Tires |
|
|
Number of Tires |
6+1 (spare tire) |
|
|
Tire Type/Size |
12.00R20 |
|
|
Track |
front |
1995mm |
|
rear |
1800mm |
|
|
Upper body specifications |
||
|
Tank |
Capacity |
8000 liters |
|
Material |
4mm carbon steel |
|
|
Water pump |
Flow |
40m3/h |
|
Vertical Suction |
≥6 m |
|
|
Priming Time |
<5 min |
|
|
Lift of pump |
45m |
|
|
Spraying system |
Spray width |
≥14 |
|
Water cannon range |
≥23 |
|
|
Nozzles |
Front, side and rear nozzles |
|
